Cooling fan series

MG14025 High Static Pressure 140 x 140 x 25 mm - A Type

The MG14025 DC axial fan is a 140 x 140 x 25 mm - A Type solution for server, cabinet and equipment ventilation. Select by airflow and static pressure at the installed operating point, then validate the chosen variant with a sample on your own unit.

MG14025 High Static Pressure 140 x 140 x 25 mm - A Type
Request a sample →Request a quote

Available variants

MODELS ＆ OPERATING DATA

Values below are loaded from the current catalogue record. Confirm the selected operating point and application before approval.

ModelVoltageRated currentInput powerSpeedAirflowStatic pressureNoise
MG14025L12X12 V DC0.1 A1.2 W150062.07 CFM1.3 mmH₂O28 dBA
MG14025L24X24 V DC0.05 A1.2 W150062.07 CFM1.3 mmH₂O28 dBA
MG14025L48X48 V DC0.03 A1.44 W150062.07 CFM1.3 mmH₂O28 dBA
MG14025M12X12 V DC0.23 A2.76 W200088.28 CFM2.54 mmH₂O36 dBA
MG14025M24X24 V DC0.12 A2.88 W200088.28 CFM2.54 mmH₂O36 dBA
MG14025M48X48 V DC0.06 A2.88 W200088.28 CFM2.54 mmH₂O36 dBA
MG14025H12X12 V DC0.47 A5.64 W2500112.8 CFM3.87 mmH₂O43.1 dBA
MG14025H24X24 V DC0.24 A5.76 W2500112.8 CFM3.87 mmH₂O43.1 dBA
MG14025H48X48 V DC0.12 A5.76 W2500112.8 CFM3.87 mmH₂O43.1 dBA
MG14025HH12X12 V DC1 A12 W2900133.43 CFM5.35 mmH₂O47.1 dBA
MG14025HH24X24 V DC0.5 A12 W2900133.43 CFM5.35 mmH₂O47.1 dBA
MG14025HH48X48 V DC0.25 A12 W2900133.43 CFM5.35 mmH₂O47.1 dBA

Built to order

CUSTOMIZATION ＆ OPTIONS

MEGA supplies the fan itself; system-level air paths, ducting and cabinet integration remain the responsibility of the system integrator.
