MG9225 High Static Pressure 92 x 92 x 25 mm - B Type

Name: MG9225 High Static Pressure 92 x 92 x 25 mm - B Type
Brand: MEGA Tech
SKU: MG9225

The MG9225 DC axial fan is a 92 x 92 x 25 mm - B Type solution for networking, industrial electronics and equipment enclosures. Select by airflow and static pressure at the installed operating point, then validate the chosen variant with a sample on your own unit.

Request a sample →Request a quote

Selection highlights

Available variants

High Static Pressure up to 9.68 mmH₂O
Pressure-band options: H up to 8.32 mmH₂O, HH up to 4.99 mmH₂O.
Compact 92 x 92 x 25 mm format with 1.44–7.8 W input power
Up to 4,500 RPM and 73.9 CFM
Noise range 27.5–50.1 dBA
PWM speed control, FG/RD tachometer output, IP rating, lead wire and connector can be reviewed and configured on request; confirm the final configuration before sampling.
MEGA Tech supplies the fan itself — cabinet airflow design, coils and liquid loops remain the system integrator responsibility.
